Posted on 31 January 202518 April 2025 by Wouter van Spoorlaar — Leave a comment

Spoorlight – Interior lighting for model railroads

General features:
✔️ 220uF capacitor for stable lighting
✔️ Potentiometer for adjustable brightness
✔️ No soldering required with Minitrix & Fleischmann

Variant	Properties	Lengths
Universal N	Easily customizable	61mm – 160mm
Minitrix	Simple installation without soldering (sliding pins on the chassis)	150mm, 115mm
Fleischmann	Special screws, no soldering required	150mm, 135mm, 120mm, 105mm
Roco/Fleischmann Eurofima	Customized circuit board	150mm
Hobbytrain Railjet	Steering set & set with 3 circuit boards for intermediate carriages	–
Small carriages	Compact printed circuit boards	35mm, 50mm, 60mm
Double-decker coach	Suitable for Jägerndorfer, Fleischmann & Minitrix. Warm white or cool white LEDs	144mm (top) 90mm (bottom)

Further variants will follow. Suggestions are always welcome!

Posted on 5 November 202418 April 2025 by Wouter van Spoorlaar — Leave a comment

Spoorlaar decoder tester

The Spoorlaar decoder tester SPLR6500 is one of my recent developments. I designed these specifically with N gauge in mind. Unlike the ESU testers, the SPLR6500 does have the AUX5&6 of the NEXT18 connected. Also on the SPLR6500 is an MTC14 jack! Everything is beautifully incorporated into a compact size of only 6 x 8 cm. And thanks to the expansion header, H0 riders need not worry, as expansions are on the horizon.

Spoorlaar PLUX16, NEXT18, MTC14 & NEM651 decoder tester

Small decoder tester for N-scale decoders. (About the size of a playing card).

NEXT18 – PLUX16 – MTC14 – NEM651

Extensions for E24/NEXT28 and wire are planned. Requests are welcome, please send an email 🙂

€ 21,48 Incl. BTW

Store Now

Posted on 5 November 202418 April 2025 by Wouter van Spoorlaar — Leave a comment

Delivery Fleischmann 1600 sets

The first ten Fleischmann 1600/1700/1800 sets have already been shipped. For now, just the NEM651 version. More to follow soon!

The kits now consist of a circuit board with decoder connector, 2 LED circuit boards, 2 noses and 2 light masks.

Fleischmann 1600/1700/1800 circuit boards set

Circuit board version: NEM651

– NEM651

– Front and closing lights

– Cab lighting

€ 15,69 Incl. BTW

Store Now

Posted on 22 October 202418 April 2025 by Wouter van Spoorlaar — Leave a comment

Progress Minitrix MaK 6400 circuit boards 22/10/24

The first circuit boards has now been tested. In doing so I discovered that the placement of the screw holes was not correct, also the LEDs of the shunting light did not work correctly. This has been fixed with the second circuit board version. Meanwhile, these are also already on their way.

Testing the light functions was a success. I used a tOm decoder for this purpose. When using a speaker, the cab lamp will be dropped, the shunting lighting should be connected separately to the decoder with a wire. For reliable operation of the shunting lighting, a capacitor will also be included.

The LED lighting will be available with white or yellow LEDs.
